Inter-m PC-1235 - Electrical Parts List; AMP BD Components

Ref No. Part No. Description Value Qty
C815 3509102530-T CAP CE B 0.001UF 50V J 0.001/50 1
3509103530-T CAP CE F 0.01UF 50V Z(PC-1235) 0.01/50 1
3509101130-T CAP CE SL 100PF 50V J(PC-1650) 100P 1
C207 3678220177 CAP M1 DM 10C 220J5 220J 1
C202 3688471118 CAP MO SR22C 471JA 471J 1
C208 3678050177 CAP M1 DM10C 050D5 050D 1
CN201 4428595002 LW5267/LWB0640/2.5MM-02P MOLEX 5267-2P 1
CON203 4428596604 LOCK WAFER LW-1143-04P CON4P 1
CN204 4428596604 LOCK WAFER LW-1143-04P CON4P 1
CN202 4355826625 CON ASS'Y 7P CON7P 1
L201 2648099940 COIL INDUCTOR 1.2UH 1.2uH 1
D201-209 2058304100 DIODE IN4148M 1N 4148 9
D210-211 2058322100 DIODE 1SS145 ROHM ISS 142 2
D212-213 2058100110 DIODE RL207 PYUNG CHANG RL207 2
C206 3409810141-T CAP AF NP 100UF 25V 100/25 NP 1
C211-212 3409247991-T CAP AF RSG 4.7UF 100V 5 P 4.7/100 2
C201 3409547031-T CAP AF 47UF 16V (MOSE) 47/16 1
C205 3698152198 CAP NPP POLY 152J 2J 0.0015/500V 1
C209-210 3609222120-T CAP MA 0.0022UF 100V J 0.0022/100(M) 2
C203-204 C213-214 3609104122-T CAP MA 0.1UF 100V J SMALL 0.1/100(M) 4
R236-237 R242-243 3049478783 RES CE 0.47 5W J T HAN NAE(PC-1235) 0.47 5W 4
R236-237 R242-243 3049478783 RES CE 0.47 5W J T HAN NAE(PC-1650) 0.47 5W 10
R248-249 R265-266
R271-272
3009132973 RES CF 1.3K 1/5W J N(PC-1235) 1.3K 1
3009102973 RES CF 1K 1/5W J N(PC-1650) 1K 1
R216 3009182973 RES CF 1.8K 1/5W J N 1.8K 1
R213 3009101973 RES CF 100 1/5W J N 100 1
R234-235 R240-241 3079101275 RES ERD-2FCVG 101T 1/4W R(PC-1235) 100 1/4W 4
R234-235 R240-241 3079101275 RES ERD-2FCVG 101T 1/4W R(PC-1650) 100 1/4W 10
R246-247 R263-264
R269-270
R252-253 3009104973 RES CF 100K 1/5W J N 100K 2
R251 3059100772 RES CE 10 5W JN 10 5W 1
3009121973 RES CF 120 1/5W J N(PC-1235) 120 1
3009221973 RES CF 220 1/5W J N(PC-1650) 220 1
R205 3009123973 RES CF 12K 1/5W J N 12K 1
R254 3009184973 RES CF 180K 1/5W J N 180K 1
R206 3009102973 RES CF 1K 1/5W J N 1K 1
R222-223 R226-229 3089221275 RES NFR 220 1/4W J R PHILKO 220 1/4W 6
R258 3009224973 RES CF 220K 1/5W J N 220K 1
R218-219 3002220953 RES CF 22K 1/5W F N 22K 1% 2
R255-256 3009223973 RES CF 22K 1/5W J N 22K 2
R201 3009271973 RES CF 270 1/5W J N 270 1
R230-231 3089332275 RES NFR 3.3K 1/4W J R PHILKO 3.3K 1/4W 2
R232-233 R238-239 3089479275 RES NFR 4.7 1/4W J R PHILKO(PC-1235) 4.7 1/4W 4
ELECTRICAL PARTS LIST (PC-1235/1650)
C215
R203
R207
AMP B'D (400349500)
