Inter-m PC-1650 User Manual

R232-233 R238-239 3089479275 RES NFR 4.7 1/4W J R PHILKO(PC-1650) 4.7 1/4W 10
R244-245 R261-262
R267-268
R250 3039479575-T RES MO 4.7 2W J RADIAL 4.7 2W 1
R217 3009471973 RES CF 470 1/5W J N 470 1
R202 R210-212 3009473973 RES CF 47K 1/5W J N(PC-1235) 47K 6
R224-225
R210-212 3009683973 RES CF 68K 1/5W J N(PC-1650) 68K 3
R224-225 3009393973 RES CF 39K 1/5W J N(PC-1650) 39KK 2
R204 R208-209 3009561973 RES CF 560 1/5W J N 560 3
R257 3009683973 RES CF 68K 1/5W J N 68K 1
R214-215 3089820275 RES NFR 82 1/4W J R PHILKO 82 1/4W 2
RY201 5528006600 RELAY 833H-1C-C24V(SONGCHUAN) HR702H 1
R220-221 3089100275 RES NFR 10 1/4W J R PHILKO 10 1/4W 2
PO201 2438007994 POSISTOR PTFLO4BE471Q2N34BO BE471TS 1
PO202 2438007993 POSISTOR PTFM04BE222Q2N34B0 BE471TS 1
PO203 2438007995 POSISTOR PTFM04BH471Q2N34B0 BH471TS 1
Q207 2008405999 TR NPN 2SC4001 NEC 2SC 4001 1
Q213 Q215 2028407122 TR NPN 2SC5200 TOSHIBA(PC-1235) 2SC3281 2
Q213 Q215 2028427998 TR 2SC 3856 W/ACC(PC-1650) 2SC 3856 5
Q217 Q219 Q221
Q208 Q211 2028407990 KTC4370A-Y-U C4370 2
Q204-205 Q209 2008606108-T KTC3200-BL-AT C3200BL 3
Q206 2008005999 TR PNP 2SA 1546 NEC 2SA 1546 1
Q214 Q216 2028107118 TR PNP 2SA1943 TOSHIBA(PC-1235) 2SA1943 2
Q214 Q216 2028117994 TR PNP 2SA 1492 W/ACC(PC-1650) 2SA 1492 5
Q218 Q220 Q222
Q212 2028107984 KTA1659A-Y-U A1659 1
Q201 Q210 2008206104-T KTA1268-BL-AT KTA 1268BL 2
Q202-203 2008606105-T TR NPN KTA1266-Y-AT TO-92(PC-1235) A1266 2
2008206106-T KTA2400-GR-AT(PC-1650) A2400 2
VR201 3248347120-T RES SEMI RH063MCS2R 470B 1
GND 4235007210 GND TERMINAL (POWER B'D) GND 1
7502089910 HEAT SINK (L=320) PC-1235 HEAT SINK 1
7502089920 HEAT SINK (L=2500) PC-1650 HEAT SINK 1
6705998410 SPACER HOLDER SPACER 3
6705998510 SPACER PS-A152 SPACER 3
WASHER 8329030011
WASHER THD/IN Φ 3 Y
WASHER 1
6503983020 BRACKET TR P-1500(PC-1235) BRACKET 2
6503983010 BRACKET TR P-3500(PC-1650) BRACKET 2
2128310600 IC EPROM 27C512 ART LONG DELAY 27512 1
4448000097 SOCKET IC ZT-28-A(28PIN) 28P 1
C15-18 C28-29 C31 3509103530-T CAP CE F 0.01UF 50V Z 0.01/50 7
C7-8 C12 C21-22 3509104530-T CAP CE F 0.1UF 50V Z 0.1/50 7
C24-25
C30 3509331130-T CAP CE SL 330PF 50V J 330P 1
C3-4 3509330130-T CAP CE SL 33PF 50V J 33P 2
C51 C54 3539473531-A CAP CE F 47000PF 50V Z AXIAL 47000P 2
CN206 4428595003 LW5267/LWB0640/2.5MM-03P CON3P 1
SPACER
BRACKET
IC3
DSP B'D (4003486800)
HEAT SINK
