AD629 - Instructions for Use - EN Page 47
Signal Indicator(VU)
Time weighting: 300mS
Dynamic range: 23dB
Rectifier characteristics: RMS
Selectable inputs are provide with an attenuator by which the level can be
adjusted to the indicator reference position(0dB)
Data Connections
(sockets)
4 x USB A (compatible with USB 1.1 and later)
1 x USB B (compatible with USB 1.1 and later)
1 x LAN Ethernet
External devices (USB)
Standard PC mouse and keyboard (for data entry)
Supported printers: Standard PCL3 printers (HP, Epson, Canon)
Input Specifications
TB
100uVrms at max. gain for 0dB reading
Input impedance : 3.2KOhm
Mic.2
100uVrms at max. gain for 0dB reading
Input impedance : 3.2KOhm
CD
7mVrms at max. gain for 0dB reading
Input impedance : 47KOhm
TF (side panel)
100uVrms at max. gain for 0dB reading
Input impedance : 3.2KOhm
TF (front panel)
100uVrms at max. gain for 0dB reading
Input impedance : 3.2KOhm
Wave files
Plays wave file from hard disk drive
Output Specifications
FF1 & 2
7Vrms at min. 2KOhm load
60-20000Hz -3dB
Left & Right
7Vrms at 10 Ohms load
60-20000Hz -3dB
Ins. Left & Right
7Vrms at 10 Ohms load
60-20000Hz -3dB
Bone
7Vrms at 10 Ohms load
60-10000Hz -3dB
Ins. Mask
7Vrms at 10 Ohms load
60-20000Hz -3dB
Monitor(side
panel)
2x 3Vrms at 32 Ohms / 1.5Vrms at 8 Ohms load
60-20000Hz -3dB
Display
5,7 inch high resolution color display 640x480 pixels
Compatible software
Diagnostic Suite - Noah, OtoAccess and XML compatible
Dimensions (LxWxH)
36.5 x 29.5 x 6.5 cm / 14.4 x 11.6 x 2.6 inches
Weight
3.3kg/6.3lb
Power supply
100-240 V~, 50-60Hz max 0.5A
Operation environment
Temperature: 15-35°C
Re. Humidity: 30-90% Non condensing
Transport and storage
Transport temperature: -20-50°C
Storage temperature: 0-50°C
Re. Humidity: 10-95% Non condensing
