5
Table Sa
w
Mod. RT-40
Technical Data
Standard saw blade diameter……………………………….………………………………… mm 350 (14”)
Maximum saw blade diameter………………………………………………………………… mm 400 (16”)
Shaft diameter…………………………………………………………………………………… mm 30
Maximum cut (350 mm diameter saw)………………………………………………………... mm 115 (4-1/2”)
Maximum cut (400 mm diameter saw)…………………………..…………………………… mm 140 (5-1/2”)
Maximum height of cut at 45º (350 mm diameter saw)…………………………………….. mm 80 (3-1/8”)
Maximum height of cut at 45º (400 mm diameter saw)……….……………………………… mm 105 (4-1/8”)
Motor 3 / phase…………………………………....……………………………………………… HP 7,5
Shaft speed………………………………………………………………………………………. RPM 3000
Maximum dado capacity………………………………………………………………………... mm 40 (1-9/16”)
Maximum rip capacity……………………………………………………………………………. mm 850 (33-7/16”)
Distance from front of the table to center of the saw blade saw…………………………… mm 580 (22-13-16”)
Distance from front of table to the edge of a Ø 350 mm saw at maximum height………… mm 435 (17-1/8”)
Height from floor to table top………………………………………………………………….. mm 850 (33-7/16”)
Table dimensions……………………………………………………………………………….. mm
inch
1000 x 1000
39-3/8” x 39 –
3/8”
Table dimensions including 2 extensions…………………………………………………… mm 1500 x 1100
59” x 43-5/16”
Saw tilt to the right………………………………………………………………………………. º 45º
Approx. net weight with motor…………………………………………………………………. kg 543 (1195 Lbs)
Accessories
1 Special wrench
1 Instruction Manual
