1 7 8
Place headset in ear within 5 second
Insert the headset in your ear, while twisting the head-
set backwards. The BCM must touch the ear canal and
should point downwards once inserted.
Push headset fully into ear
Pull ear back with your other hand and push the head-
set forward and into the ear canal. The BCM must touch
the ear canal and point downward once inserted.
Place Soft Spring in ear
Use your index nger to push the Soft Spring into the
upper bend of your ear to ensure a secure headset t
and consistent pressure on the BCM.
Place Cable Retainer behind ear
Place the Cable Retainer behind your ear to ensure the
cable is held comfortably and securely over the ear.
Test headset on radio
Test your voice quality by transmitting to another radio.
If transmission is low or the headset is sitting loose,
ret the headset and/or try another Soft Spring or foam
tip size.
Hold headset before tting
Hold the headset with your thumb and rst two ngers
and the Soft Spring pointing upward and forward with
the loudspeaker toward your ear.
2
Compress foam tip
Roll and compress the tip into a thin round cylinder with
as small as possible diameter. The cylinder should be
free from wrinkles.
53 4 6
Hold headset in ear for 20 seconds
Hold headset in your ear for at least 20 seconds until
the foam has expanded.
