INVT CHV100-2R2G-4 User Manual

List of Function Parameters
124
Function
Code
Name Description
Factory
Setting
Modify LCD Display
P8.30
Auxiliary motor1
START/STOP
delay time
0.0~3600.0s 5.0s ○
MOTOR 1
DELAY
P8.31
Auxiliary motor2
START/STOP
delay time
0.0~3600.0s 5.0s ○
MOTOR 2
DELAY
P8.32
Brake threshold
voltage
320.0~750.0V 700.0V ○ BRAK VOLT
P8.33
Low-frequency
threshold of
restraining
oscillation
0~9999 1000 ○
LO FREQ
RESTRAIN
P8.34
High-frequency
threshold of
restraining
oscillation
0~9999 1000 ○
HI FREQ
RESTRAIN
P9 Group: PID Control
P9.00
PID preset source
selection
0: Keypad
1: AI1
2: AI2
3: AI3
4: AI4
5: HDI1
6: HDI2
7: Communication
8: Simple PLC
0 ○ PID PRESET
P9.01 Keypad PID preset 0.0%~100.0% 0.0% ○
KEYPAD PID
SET
P9.02
PID feedback
source selection
0: AI1
1: AI2
2: AI3
3: AI4
4: AI1-AI2
5: AI3-AI4
6: HDI1
7: HDI2
8: HDI1-HDI2
9: Communication
0 ○
PID
FEEDBACK
P9.03
PID output
characteristics
0: Positive
1: Negative
0 ○ PID OUTPUT
