A
Figure A
POSITIVE BATTERY
LEAD AND TERMINAL
NEGATIVE BATTERY
LEAD AND TERMINAL
ALTERNATIVE DC
INPUT ACCESS COVER
BATTERY BOX
MOUNTING SCREWS
FUSE LINK
NEGATIVE TERMINAL
POSITIVE TERMINAL
Detail A
