ION iCade Service Manual

P/N Part Name Specification Unit Q'ty
10520162 Battery touch 1
ICG04，chrome plated，T=0.5mm，V1.0
PCS 1
10520163 Battery touch 2
ICG04，chrome plated，T=0.5mm，V1.0
PCS 1
10520164 Battery touch 3
ICG04，chrome plated，T=0.5mm，V1.0
PCS 1
20020069 Top plastic panel ICG04,DN-PC2025 ABS, black, 255*182.74*52.03mm,V1.0 PCS 1
20030066 Bottom plastic cover
ICG04，DN-PC3030，ABS，black，255*81.3mm，V1.0
PCS 1
20060018 Battery cover
ICG04，DN-PC6008，ABS，black，71.27*39.7mm，V1.0
PCS 1
20110089 lens
ICG04，DN-PL1072，PC，34*25mm，V1.0
PCS 1
20630072 iPad dock
ICG04,ABS，black，67.42*33.87mm，V1.0
PCS 1
20360061 Joystic gasket
ICG04, ABS,black，T=1.5,V1.0
pcs 1
60190116 joystick
ICG04，JMHO
PCS 1
30060319 foam T=2.0,V1.0 PCS 1
70010081 screw Φ3*8mm, D6mm, PCS 16
70010010 screw Φ2.6*8mm, D5.5mm, PCS 4
70090071 gasket Φ3.2*Φ6*1mm PCS 4
70010093 screw Φ3*8mm D6mm, PCS 4
40010022 DC Jack AN-J0122,DC-05(Φ
2.0) PCS 1
12020040 Button Red PCS 2
12020039 button White PCS 2
12020041 Button Black PCS 4
16040673 cable
AN-W4243,22#，UL1007，L=300mm
PCS 4
16040674 cable
AN-W4244,22#，UL1007，L=200mm
PCS 1
16010009 ribbon cable AN-W109,2P,22#,UL1007,150mm PCS 2
26010411 PCB AN-B10359,47.5*25.75*1.0mm, LED PCB V1.0 PCS 1
11170022 SMD resistor 1/8W,100Ω,±5%,0805 PCS 1
18040137 LED AN-L0004,KPT-3216SRC,1206 Red PCS 1

ION iCade Specifications

General

Device type	Special
Buttons quantity	8
Gaming control technology	Analogue / Digital
Gaming platforms supported	Tablet PC
Gaming control function buttons	-
Connectivity technology	Wireless
Battery type	AA
Number of batteries supported	2
Product color	Multicolor
Housing material	Wood
Batteries included	Yes
Number of products included	1 pc(s)

Weight and Dimensions

Weight	- g
