AUX1
Lock+
24V @ 0,5A
RS485 -
IN1
AUX1
Lock-
M
RS485 +
IN2
A Puerto Ethernet
Ethernet port
B Terminal extraíble de 10 polos
Removable 10-pole terminal
C Restaurar la configuración de fábrica
Factory reset
Mantén presionado durante 10 segundos al reiniciar
Hold for 10 seconds on reboot
B
51mm
A Toma de red / Network Socket
Tarjeta de red / Network Card :
10/100Mbps PoE IEEE 802.3af.
OIOGIBBIGBrlBrRj-45 Plug
RJ-45 EIA/TIA 568B CAT5/6
Terminales y Conectores
Terminals and Connectors
51mm
Made in italy
