Washer-Extractors
14
5-08-51
Electrical Installation Requirements - Model IWF025 (2-speed)
Only trained personnel should perform this
procedure. Use caution while servicing
machines with covers removed and power
applied.
W700
WARNING
Boiler Fed/Steam Heat Electric Heat
Code
Voltage
Cycle
Phase
Wire
Full Load
Amps
Recommended Circuit Breaker
(US-market)
AWG/mm
2
kW Standard
Heating Elements
Full Load
Amps
Recommended Circuit Breaker
(US-market)
AWG/mm
2
US NON-US US NON-US
N 440-480 50/60 3 3+PE 1 10 6 14/2.5
3x3 kW
N/A N/A N/A
N/A
P 380-415 50/60 3 3+N+PE 1 10 6 14/2.5 17.3 25 20
14/2.5
Q 200-240 50/60 3 3+PE 2.5 10 6 14/2.5 27.1 30 25
14/2.5
X 200-240 50/60 1/3 2/3+PE 2.5 10 6 14/2.5 N/A N/A N/A
N/A
Alternative Electric Heat Options
N 440-480 50/60 3 3+PE
3x1.4 kW
N/A N/A N/A
N/A
P 380-415 50/60 3 3+N+PE 8.6 10 10
14/2.5
Q 200-240 50/60 3 3+PE 14 15 16
14/2.5
X 200-240 50/60 1/3 2/3+PE N/A N/A N/A
N/A
N 440-480 50/60 3 3+PE
3x2 kW
N/A N/A N/A
N/A
P 380-415 50/60 3 3+N+PE 11.9
15 16
14/2.5
Q 200-240 50/60 3 3+PE
18.9
25 20
14/2.5
X 200-240 50/60 1/3 2/3+PE N/A N/A N/A
N/A
N 440-480 50/60 3 3+PE
3x4 kW
19.8 25 20
14/2.5
P 380-415 50/60 3 3+N+PE 22.8
30 25
14/2.5
Q 200-240 50/60 3 3+PE N/A N/A N/A
N/A
X 200-240 50/60 1/3 2/3+PE N/A N/A N/A
N/A
Table 3
