IRIS IP-700 - 11. Part list

PART NO.
QTY
DESCRIPTION
1
1
FRAME
2
8
Nut, Hex M10
3
8
Spring Lock Washer, M10
4
4
Washer, M10
5
4
Screws, Hex Head M10X35
6
1
HOPPER RING
7
10
Nut, Hex M12
8
10
Washer, M12
9
2
HOPPER BRACE
10
4
Screws, Hex Head M12X35
11
6
Screws, Hex Head M12X40
12
1
FRAME TIE ROD(RIGHT)
14
1
Screws, Hex Head M12X65
15
1
BAKELITE DISC
16
1
LEVER
17
1
RUBBER HANDLE
18
1
COMPRESSION-SPRING
19
6
Nut, Self-locking, M10
20
10
Nut, Hex M8
21
2
Washer, M8
22
1
LEVER GUIDE
23
2
Nut, Hex M22
24
2
Spring Lock Washer, M22
25
2
LOW LINK-PIN
26
1
FRAME TIE ROD(LIGHT)
27
2
Screws, Hex Head M8X30
28
2
R PIN
29
4
Washer, M10
30
4
Screws, Hex Head M10X35
31
2
Screws, Hex Head M14X65
32
1
AGITATOR
33
1
AGITATOR FIXING PLATE
34
2
Nut, Hex M14
35
1
HOPPER
36
1
LOCKING BUSH
37
6
Nut, Hex M10
38
6
Screws, Hex Head M10X25
39
1
HOPPER LOW PLATE
