Winch Installation
1. Bolt winch to cradle with gearbox to the left hand
side of vehicle and cable spooling from bottom of
the cable drum using bolts and washers provided.
2. Bolt fairlead to recess in front of bull bar using
bolts, washers and nuts provided.
3. Fit bull bar to vehicle referring to steps of bull bar
fitting instructions.
4. Mount control box in desired location.
5. Connect three colour coded cables to the
corresponding poles on winch motor.
