GSM router iRZ RUH
2
(HSUPA/HSDPA/UMTS/EDGE/GPRS) 3G
User manual
10
Fig. 2.5.2 Rear view
The numbers in Figure 2.5.2 indicate:
1. Ethernet network connector;
2. USB Host connector;
3. SMA connector to connect the GSM antenna;
4. Power connector.
1
2
3
4
