5 NORMAL OPERATIONS & FUNCTIONS DACS-W Operation Manual
5-20
5.6.1.6 Product Code
This item defines the product code of the target product which is displayed on the RCU.
Up to 4 characters can be input for the Product Code.
Follow the procedure described below to set the Product Code.
4. Press or to align cursor with desired
characters or numbers.
5. Press .
The characters are registered.
6. After all characters are registered, press .
The registered name appears on the Preset
menu and Product Name setting is complete.
Figure 5-37 Product Name Menu
1. Call up the Preset menu.
2. Press to scroll the cursor to "Product
Code".
3. Press .
The Product Code menu appears.
Figure 5-38 Preset Menu
4. Press or to align cursor with desired
characters or numbers.
5. Press .
The product code are registered.
6. After all characters are registered, press .
The registered code appears on the Preset
menu and Product Code setting is complete.
Figure 5-39 Product Code Menu
ENTER
▼
▲
SELECT
ITEM
EXIT
Entered Character (Number)
[Product Name]
0 1 2 3 4 5 6 7 8 9 A B C D E F
V W X Y Z ! " # $ % & ' ( ) * +
M
G H I J K L M N O P Q R S T U
ENTER
▼
SELECT
ITEM
[Preset]
No. 2
* Product Length 250 mm
* Product Name M
* Product Code
ENTER
▼
▲
SELECT
ITEM
EXIT
Entered Character(Number)
[Product Name]
0 1 2 3 4 5 6 7 8 9 A B C D E F
V W X Y Z ! " # $ % & ' ( ) * +
8
G H I J K L M N O P Q R S T U
To Next Page
