Islander MR3 Series - Page 2

4
1
5
2
6
3
1
0
7
11
8
12
9
1
3
14
1
6
1
7
1
8
2
0
1
9
2
5
2
3
1
5
Frame Assembly - MAINTENANCE - Rinse and dry after use.
Foot/Reel Seat - MAINTENANCE - Rinse and dry after use.
Pawl Assembly(ies) - MAINTENANCE - See References 16,17,18.
Spindle - MAINTENANCE - Remove all the old lubricant and any grit from the
spindle and apply a small amount of grease to the base of the spindle.
Clutch Surface - MAINTENANCE - Wipe surface to remove excess oil and graphite.
Apply a small amount of oil and powered graphite to the cork surface and work it
in with your finger. - See References 19 and 20 for further instruction.
Spindle O-Ring - MAINTENANCE. Remove old grease and any grit prior to clutch
(ref. 6) installation.
1
2
3,4
5
6
7
24
21
22
A. CARE AND MAINTENANCE
A. CARE AND MAINTENANC
tof
While
t
hi
s
reel i
sco
n
st
r
uct
e
dou
insecorrosion resistant materials, it is best to r
use
,
y
our reel off with warm water after each
a
ter
.
particularl
y
after exposure to salt w
a
Spool Assembly - MAINTENANCE - Rinse and dry after use.
Handle Assemby(ies) - MAINTENANCE - See ref. 24.
Front Spool Bearing - MAINTENANCE - Remove old grease and grit with a dry
cloth or one with a small amount of isopropyl alcohol (at least 70% USP). Apply a
small amount of grease to the exposed bearing shield.
Dragspring - MAINTENANCE - Remove old grease and any grit. Soapy water and a
tooth brush work the best. Rinse with fresh water. There is no need to regrease
the dragspring as lubricant from the Front Spool Bearing (ref. 11) will migrate into
the dragspring.
Dragknob Washer - MAINTENANCE - Remove old grease and any grit. There is no
need to regrease the washer, as grease from the dragknob (ref. 13) will migrate.
8
9,10
11
12
13
For parts and service
call toll free: 1-888-404-1119
www.mikesreelrepair.com
