Product Quick Guide:
Hardware Guide
D-300-PFS
1. Aluminum Bezel
(3 color Options: Red, Blue, Silver)
2. Power LED
3. Alarm reset
4. HDD LED
5. Temp Sensor 1 LED (TC-ISF08 require)
6. Fan LED (TC-ISF08 require)
7. Temp Sensor 2 LED (TC-ISF08 require)
8. Handle
15.
10. Key lock
11. USB 2.0
12. Reset button
13. Power button
14. 3.5” Bay X1
16. Ear Mount
9. For ATX Power Supply
17. Expansion slot
18. 1x 60mm Fan
19. Cross bar/ Fan bar
20. For ATX, micro-ATX MB
21. For Optional Sensor Board TC-ISF08
22. Removable Air Filter
Front View
Front Open View
1
2
3
Rear View
Top View
16
17
18
4
6
5 7
19
20
21
22
8 9 10
15
11
12 13 14
5.25” Bay X2
