6A–10 ENGINE MECHANICAL
6. Disconnect the bypass hose.
7. Loosen the fixing nuts and bolts from the water
pump.
8. Remove the water pump from the front plate.
9. Discard the gaskets.
Legend
(1) Adapter
(2) Fan pulley
(3) Water pump
(4) Bypass hose
(5) Water duct
(6) Water duct
5. Remove the adapter and fan pulley.
2
1
3
4
5
6
030EY00023
