2. GENERAL INFORMATION
5
1. EPA AND CARB CERTIFIED ENGINE DATA AND SPECIFICATIONS
Se rapporter à la fin de ce document pour les informations EPA en français.
(1) Model AU-4LE1T
ISUZU engine model name AU-4LE1T
Engine family *SZXL02.2UTA
Engine code 4LE1XXXXX-XX
Engine type Water-Cooled, four cycle, in-line overhead valve type
Combustion type Swirl chamber type
No. of cylinders – bore × stroke mm(in) 4 – 85 × 96 (3.35 × 3.78)
Engine displacement L(cid) 2.179 (133)
Compression ratio 21.5 to 1
Firing order 1 – 3 – 4 – 2
*2 Rated power: SAE NET kW(hp)/min
-1
40 (53.6) / 2200
*2 Fuel flow at max rated power (mm
3
/stroke) 46.3
Exhaust emission control system EM, IDI, TC, EGR
Injection pump Bosch, PFR type
Governor Variable speed, Mechanical type
* Mark ; Put a letter codes for model year on the top of the letters.
Y : 2000, 1 : 2001, 2 : 2002, 3 : 2003, 4 : 2004, 5 : 2005, 6 : 2006, 7 : 2007, 8 : 2008, 9 : 2009, Model Year
Engine code varies depending on each engine.
