Isuzu C-240PW-28 - Fuel Injector Assembly; Fuel Injector Test;Adjustment

ARMY TM 9-2815-254-24
AIR FORCE TO 38G1-94-2
d. Wash all parts in dean diesel fuel. Dry with compressed air.
3-10.5. Assembly (Fuel Injector).
a. If removed, install screw (22, FIGURE 3-4), new gasket (24), and connector (23) in holder (25).
b. Install nozzle (21) and retainer nut (20) on holder (25).
c. Install pushrod (19), spring (18), and washer (17) in holder (25).
d. Install adjusting screw (16).
NOTE
New gasket (15) and cap nut (14) will be installed after adjustment,
paragraph 3-10.6.
3-10.6. Test/Adjustment.
NOTE
Perform step a through c if cap nut (14, FIGURE 3-4) is not loose.
a. Place fuel injector in a vise and clamp on holder (25).
b. Remove cap nut (14).
c. Remove fuel injector from vise.
d. Attach fuel injector to a fuel injector tester. Point fuel injector into a clear container.
Keep body clear of test spray. Fluid can be injected into bloodstream
causing blood poisoning and possible death.
3-29
