SECTION VI. LUBRICATION SYSTEM
3-14.
OIL FILTER.
3-14.1. Cartridge Replacement.
a. Drain lubrication system, refer to end item maintenance manual.
b. Loosen cartridge (1, FIGURE 3-38) by turning counterclockwise with a filter wrench.
c.
Discard used cartridge.
d. Wipe filter head (2) with a clean rag.
e.
Apply light coat of oil to new cartridge (1) gasket.
f. Place cartridge on filter head (2) and turn clockwise until cartridge is hand-tight on head.
g.
Using filter wrench, turn cartridge an additional 1 to 1-1/4 turns.
h. Service lubrication system, refer to end item maintenance manual.
i. Operate engine and check for leakage.
3-14.2. Removal.
a. Drain lubrication system, refer to end item maintenance manual.
b. Remove four screws (3, FIGURE 3-38) securing filter head (2) to engine; remove filter head and
o-ring (4).
NOTE
Cartridge (1) does not have to to be removed to remove head.
c.
Cover opening to prevent entry of dirt.
3-14.3. Installation.
a. Wipe engine and filter head (2, FIGURE 3-38) mating areas with a clean rag.
b. Install o-ring (4). Position head (2) on engine and secure with four screws (3). Tighten screws to
168 in-lbs (19.0 Nm).
Change 2 3-69
