Isuzu D-MAX 2020 User Manual

6-105
SERVICE AND MAINTENANCE
ReplacementofWiperRubberInsert(DesignBladeType)
Removal
1. Remove the wiper blade from the
wiper arm.
2. Pull the wiper rubber insert in the
direction indicated by the arrow and
extract it from the wiper blade.
Installation
1. Insert a new wiper rubber insert into
the wiper blade.
RTUL60SH005701
Insert
Hole
RTUL60SH005801
Pull
2. Continue pushing in the wiper rubber
insert until the wiper blade's hook
engages with the hole in it, and
then confirm that the rubber insert is
securely held in place.
3. Attach the wiper blade to the wiper
arm.
RTUL60SH007101
ReplacementofWiperRubberInsert(FlatBladeType)
NOTE
• On flat blade type, the wiper rubber
cannot be replaced. When you
replace the wiper rubber, replace
the wiper blade as an assembly.
RTUL60SH010101
