4-38
CONTROLS AND INSTRUMENTS
Brake System Warning Light
AHB
This warning light should normally come
on when the starter switch is turned to the
"ON" position, and then should go out after
the engine has started.
This warning light comes on and a buzzer
sounds when the brake fluid level is too
low or leaking. If the brake fluid level is up
to specification and there is no leakage,
possible causes include:
• The brake drum-to-lining clearance
has exceeded the specified limit.
This may be due to a faulty automatic
brake adjuster.
• The servo unit is faulty.
CAUTION
If the brake system warning light comes on, immediately pull off to a safe place
well clear of traffic and contact the nearest Isuzu Dealer.
•
Model without multi-information
display (MID)
Model with MID
