4-153
CONTROLS AND INSTRUMENTS
Adjustment of HSA
Make a fine adjustment of HSA in the
following cases.
• If the brakes drag when restarting the
vehicle.
• When the vehicle moves down on a
slope when the HSA is activated.
• When the brakes are not released
when desired.
Adjustment
1. Pull the parking brake lever, make
sure the gearshift lever is placed in
"N", and then start the engine. At this
time make sure that the HSA OFF
switch is placed in "OFF" and that
HSA is enabled.
2. Fully depress the brake pedal and
release the parking brake lever.
Check that the HSA indicator light
comes on and then do the following:
If your vehicle is equipped with a
manual transmission, depress the
clutch pedal and place the gearshift
lever into any position other than "N".
If your vehicle is equipped with a
Smoother system, depress the brake
pedal and place the gearshift lever
into any position other than "N".
3. If the HSA releases the brakes too
slowly and the brakes drag when
starting the vehicle, press the "FAST"
side of the HSA adjustment switch.
If the HSA releases the brakes too
early and the vehicle moves down on
a slope when restarting the vehicle,
press the "SLOW" side of the switch.
Every time the switch is pressed, a
buzzer sounds.
4. Repeat step 3 above until the brakes
are released at when desired.
