4-187
CONTROLS AND INSTRUMENTS
FTS Model (6HK1 Engine Model)
Use the center differential lock switch when
one or more drive axle wheels are in mud
or sand, or on frozen or otherwise slippery
slope surfaces.
Stop the vehicle and press the "ON" side of
the switch. The center differential lock will
then be engaged and the center differential
lock indicator light will come on at the same
time. When the "OFF" side is pressed, the
center differential lock is disengaged and
the indicator light goes out.
Center Differential Lock Switch
V
CAUTION
When raising the vehicle with jacks,
do not engage the center differential
lock. When you rotate a wheel, the
other wheels also rotate; this is very
dangerous.
•
Center differential lock indicator
light
NOTE
When the transfer gear control switch is placed in the "LOW" position, the 4WD
mode is not canceled even if you place the 4WD switch in the "OFF" position.
When canceling the 4WD mode, bring the vehicle to a stop, depress the clutch
pedal, place the transfer gear control switch into the "HIGH" position, and then
place the 4WD switch into the "OFF" position.
When the vehicle is operated in the 4WD mode, it has a larger turning radius
than when it is operated in the 2WD mode.
•
•
