4-189
CONTROLS AND INSTRUMENTS
FSS/FTS Model
This switch is used to change between the
"HIGH" range (high speed) and the "LOW"
range (low speed) of the transfer.
1. Make sure that the vehicle is stopped
and depress the clutch pedal.
Transfer Gear Control Switch
V
NOTE
The clutch pedal must be depressed
before the transfer gear control
switch can become active.
•
2. Press the "HIGH" side or "LOW" side
of the switch. When the "LOW" side
of the switch is pressed, the transfer
LOW indicator light comes on.
HIGH : Press this side for normal driving on
a general road or highway.
LOW : Press this side for driving on a
snowy road, icy road, steep slope or
rough terrain.
ADVICE
Do not operate the transfer gear control switch while driving. Be sure to bring
the vehicle to a stop and operate the switch while depressing the clutch pedal.
•
NOTE
[FSS model, FTS model (6HH1 engine model)]
Even if the 4WD switch is placed in the "OFF" position, pressing the "LOW" side
of the transfer gear control switch puts the vehicle forcibly into the 4WD mode.
The transfer LOW indicator light does not come on unless the vehicle is in the
4WD mode (the 4WD switch is placed in the "ON" position).
[FTS model (6HK1 engine model)]
Only the transfer LOW indicator light comes on. When the transfer LOW
indicator light remains off, the transfer is in the "HIGH" range.
•
•
•
3. Make sure the transfer LOW indicator
light is on and then start driving.
Transfer LOW indicator light
