5-2
COMFORT AND CONVENIENCE
Air Outlets
2
1
3
3
4
4
4
5
5
2
1
No. Air outlets Features
1 Driver side outlet Air flow direction is adjustable with the lever.
2 Passenger side outlet Air flow direction is adjustable with the lever.
3 Door windows Air is delivered towards the door window.
4 Windshield Air is delivered towards the windshield.
5 Foot outlet Air is delivered towards the feet.
Other Models
No. Air outlets Features
1 Driver side outlet Air flow direction is adjustable with the lever.
2 Passenger side outlet Air flow direction is adjustable with the lever.
Ram Air Vent Model
1
2
