5-11
COMFORT AND CONVENIENCE
Maximum Heating
Turn the outlet selector knob (1) to the " "
position, set the air source lever (2) to the
"
" position, and turn the temperature
control knob (3) fully towards the high
temperature direction.
Set the fan speed control knob (4) to the
maximum speed position.
Turn on the warm-up switch if equipped.
Warm-Up Switch
V
→ Refer to page 4-78
NOTE
Extended use of the inside air
recirculation position causes the
windshield and windows to fog up
easily, making visibility poor.
The heat can be increased by
turning on the warm-up switch.
•
•
Bi-level Heating
Set the outlet selector knob (1) to the " "
position.
Set the air source lever (2) to the "
"
position.
Set the temperature control knob (3) to the
middle position.
Adjust the fan speed control knob (4) as
desired.
31 4
2
31
4
2
Warm-Up Switch
V
→ Refer to page 4-78
