3-7
DOORS, WINDOWS AND SEATS
Type 2
1. Remove the screw and pry open
the cover by inserting a flat head
screwdriver or similar tool into the
notch of the cover. Wrap a piece of
cloth or tape around the tip of the
screwdriver so as not to damage the
cover.
  

   
 
2. Insert a flat head screwdriver or
similar tool into the recess of the
transmission unit to remove the old
battery.
"+"side
Hook
3. Insert the new battery into the hook of
the transmission unit with its positive
side visible as shown in the diagram
on the left and press it in to fit.


 

4. Install the transmission unit and the
battery in their original position inside
the cover.
ADVICE
When closing the cover, check that
there is no dust, hair or anything
else caught underneath it. A poorly
sealed remote control unit could
become deteriorated.
•
5. Close the cover and tighten the screw.
