ITATOOLS ITA20 - Page 25

9) ESPLOSI-RICAMBI / LAYOUT-SPARE PARTS LIST / LISTE DES PIECES /ZEICHNUNGEN - RSATZTEILE
DIAGRAMAS - RECAMBIOS
Ed. 02/14
DESCRIZIONE
CODICE ITEM
DESCRIPTION
Q.TA'
Q.TY
GR.MOTORE TRAZIONE TIPO LT
A000007
LT TENSION MOTOR GROUP
1
*
BATTERIA 2A/h 14.8V
A000063
BATTERY 2A/h 14.8V
1
§
*
ASS.SCHEDA LED CON GUIDALUCE
A000097
SIGNALS CARD WITH LIGHT TRANSP
1
*
ASSIEME ECCENTRICO
A000237
EXCENTRIC SHAFT ASSEMBLED
1
ASS.MOTORE SALDATURA CONCEPT
A000238
WELDING MOTOR ASSEMBLED
1
*
ASSIEME TELAIO
A002000
MAIN FRAME ASSEMBLED
1
ASSIEME BIELLA
A002040
CONNECTING ROD ASSEMBLED
1
ASSIEME CARRELLO SALDATURA
A002070
WELDING FOOT SUPPORT ASSEMBLED
1
ASSIEME FLANGIA MOTORE
A002160
MOTOR FLANGE ASSEMBLED
1
CUSCINETTO 61808-RS1
B400186
BEARING 61808-RS1
1
RUOTA LIBERA INA HF0812
B400188
FREWHEEL INA HF0812
1
CUSCINETTO 609 2Z
B400332
BEARING 609 ZZ SKF
1
CUSCINETTO EZO 61902 ZZ
B400333
BEARING 61902 ZZ
2
VITE TCEI M4X10 UNI5931
B500035
SCREW M4X10
10
VITE TCEI M5X12 UNI5931
B500036
SCREW M5X12
5
VITE TCEI M3X8 UNI 5931
B500068
SCREW M3X8 UNI 5931
1
VITE TCEI M5X30 UNI5931
B500140
SCREW M5X30
1
VITE TCEI M4X12 UNI5931
B500158
SCREW M4X12
3
TBCR BOSSARD BN13577 3,5X20 KA35
B500208
SCREW BN13577 3,5X20 KA35
4
RONDELLE DI SICUREZZA ZIGRINATE
B500211
LOCK WASHER
8
VITE TPSCE M4X8 UNI 5933
B500214
SCREW M4X8
2
VITE TCEI M3X10 UNI 5931
B500273
SCREW M3X10
6
VITE TC IN. M2X10 UNI6107 BRUN
B500275
SCREW M2X10
2
DADO AUTOB.BAS.M6 D985 5S
B500281
SELFLOCK. NUT M6 D985 5S
1
VITE TPSCE M4X10 UNI 5933
B500336
SCREW M4X10
1
VITE STEI M4X5 UNI5923
B500379
SCREW M4X5
5
VITE AF TBC 2.9X4.5 UNI 6954 ZINC.B
B500384
SCREW 2.9X4.5
2
VITE AF TBC 2.9X6.5 UNI 6954 ZINC.B
B500385
SCREW 2.9X6.5
3
TBCR BN13577 3,5X16 KA35
B500395
SCREW 3.5X16
3
*
VITE TCEI UNC10-24X3/8" B18.3 INS.AUTOBL
B500418
SCREW TCEI UNC10-24X3/8" B18.3 AUTOBLOCK
4
RONDELLA GROOVER Ø2 UBI1751
B500444
GROOVER WASHER DIA 2 UNI1751
2
RONDELLA PS12X18X0.5 DIN988
B600112
WASHER PS12X18X0.5 DIN988
2
SEEGER EST. A12 U.7435 R150
B600159
CIRCLIP A12 DIN471
2
SEEGER X ALBERI RA3.2 U.7434 R150
B600189
CIRCLIP RA3.2 DIN6799
1
SEEGER EST. D8 U.7435 R150
B600190
CIRCLIP D8 7435
2
MOLLA TAZZA CB12.5X6.2X0.7 D.2093
B600227
CUP WASHER CB12.5X6.2X0.7 D.2093
1
MOLLA EXTRAF. G13-025ISO10243
B600343
SPRING G13-025 ISO10243
1
SEEGER D34 UNI 7435 R150
B600345
CIRCLIP D34 UNI 7435
1
SEEGER D15 UNI7435 R150
B600346
CIRCLIP D15 UNI7435 R150
1
ROND.SPESS. PS 15X21X0.5
B600376
WASHER PS 15X21X0.5
1
ROND.SPESS. PS 6X12X0.2
B600391
WASHER PS 6X21X0.2
1
SEEGER EST.D7 TIPO E DIN 471
B600457
CIRCLIP D7 DIN 471
1
SPINA CILTMP 4X12 DIN6325 R220
B700076
PIN 4X12 DIN6325
1
SPINA CILTMP 6X28 DIN6325 R220
B700101
PIN 6X28 DIN6325
1
SPINA ELAS. 3x10 UNI6873
B700103
ELASTIC PIN 3x10 UNI6873
1
SFERA ACC. DIAM. 5mm
B700325
SPHERE DIAM.5mm
8
SCHEDA POTENZA CONCEPT
B800364
ELECTRONIC POWER CARD
1
*
TASTIERA A MEMBRANA CONCEPT
B800366
KEYBOARD
1
*
MICROSWITCH TENSIONE
B800396
TENSION MICROSWITCH
1
*
KIT CAVI POTENZA
B800397
POWER CABLES KIT
1
MICROSWITCH SALDATURA
B800460
WELDING MICROSWITCH
1
*
