9) ESPLOSI-RICAMBI / LAYOUT-SPARE PARTS LIST / LISTE DES PIECES /ZEICHNUNGEN - RSATZTEILE
DIAGRAMAS - RECAMBIOS
Ed. 10/12
DESCRIZIONE
CODICE
ITEM
DESCRIPTION
Q.TA'
Q.TY
GR.MOTORE TRAZIONE A000006 TENSION MOTOR GROUP 1 *
ASS.SCHEDA LED CON GUIDALUCE A000097 SIGNALS CARD WITH LIGHT TRANSP 1 *
BATTERIA 3A/h A000115 BATTERY 3A/h 1 § *
ASSIEME ECCENTRICO A000237 EXCENTRIC SHAFT ASSEMBLED 1
ASS.MOTORE SALDATURA A000238 WELDING MOTOR ASSEMBLED 1 *
ASSIEME BIELLA A002040 CONNECTING ROD ASSEMBLED
1
ASSIEME FLANGIA MOTORE
A002160
MOTOR FLANGE ASSEMBLED
1
ASSIEME CERRELLO SALDATURA A004650 WELDING FOOT SUPPORT ASSEMBLED
1
ASSIEME TELAIO A004700 MAIN FRAME ASSEMBLED
1
CUSCINETTO 61808-RS1 B400186 BEARING 61808-RS1 2
GABBIA RULLINI 5X8X8 B400187 ROLLER BEARING 5X8X8 4
RUOTA LIBERA INA HF0812 B400188 FREWHEEL INA HF0812 1
CUSCINETTO 609 2Z B400332 BEARING 609 ZZ SKF 1
CUSCINETTO EZO 61902 ZZ B400333 BEARING 61902 ZZ 2
VITE TCEI M4X10 UNI5931 B500035 SCREW M4X10 9
VITE TCEI M5X12 UNI5931 B500036 SCREW M5X12 5
VITE TCEI M3X8 UNI 5931 B500068 SCREW M3X8 UNI 5931 1
VITE TCEI M5X30 UNI5931 B500140 SCREW M5X30 1
VITE TCEI M4X12 UNI5931 B500158 SCREW M4X12 3
TBCR BOSSARD BN13577 3,5X20 KA35 B500208 SCREW BN13577 3,5X20 KA35 4
RONDELLA DI SICUREZZA ZIGRINATA B500211 LOCK. WASHER 4
VITE TPSCE M4X8 UNI 5933 B500214 SCREW M4X8 2
VITE TCEI M3X10 UNI 5931 B500273 SCREW M3X10 6
VITE TC IN. M2X10 UNI6107 BRUN B500275 SCREW M2X10 2
DADO AUTOB.BAS.M6 D985 5S B500281 SELFLOCK. NUT M6 D985 5S 1
VITE TPSCE M4X10 UNI 5933 B500336 SCREW M4X10 2
VITE STEI M4X5 UNI5923 B500379 SCREW M4X5 5
VITE AF TBC 2.9X4.5 UNI 6954 ZINC.B B500384 SCREW 2.9X4.5 2
VITE AF TBC 2.9X6.5 UNI 6954 ZINC.B B500385 SCREW 2.9X6.5 3
TBCR BN13577 3,5X16 KA35 B500395 SCREW 3.5X16 3 *
VITE TCEI UNC10-24X3/8" B18.3 B500418 SCREW TCEI UNC10-24X3/8" B18.3 4
RONDELLA PS12X18X0.5 DIN988 B600112 WASHER PS12X18X0.5 DIN988 2
SEEGER EST. A12 U.7435 R150 B600159 CIRCLIP A12 DIN471 2
SEEGER X ALBERI RA3.2 U.7434 R150 B600189 CIRCLIP RA3.2 DIN6799 5
SEEGER EST. D8 U.7435 R150 B600190 CIRCLIP D8 7435 2
MOLLA TAZZA CB12.5X6.2X0.7 D.2093 B600227 CUP WASHER CB12.5X6.2X0.7 D.2093 1
MOLLA EXTRAF. G13-025ISO10243 B600343 SPRING G13-025 ISO10243 1
SEEGER D34 UNI 7435 R150 B600345 CIRCLIP D34 UNI 7435 1
SEEGER D15 UNI7435 R150 B600346 CIRCLIP D15 UNI7435 R150 1
ROND.SPESS. PS 15X21X0.5 B600376 WASHER PS 15X21X0.5 1
ROND.SPESS. PS 6X12X0.2 B600391 WASHER PS 6X21X0.2 1
SEEGER EST.D7 TIPO E DIN 471 B600457 CIRCLIP D7 DIN 471 1
SPINA CILTMP 4X12 DIN6325 R220 B700076 PIN 4X12 DIN6325 1
SPINA CILTMP 6X28 DIN6325 R220 B700101 PIN 6X28 DIN6325 1
SPINA ELAS. 3x10 UNI6873 B700103 ELASTIC PIN 3x10 UNI6873 1
SFERA ACC. DIAM. 5mm B700325 SPHERE DIAM.5mm 8
TASTIERA A MEMBRANA CONCEPT B800366 KEYBOARD 1 *
MICROSWITCH SALDATURA B800378 WELDING MICROSWITCH 1 *
MICROSWITCH TENSIONE B800396 TENSION MICROSWITCH 1 *
