FUSES
F1&F2
BATTERY LEAD
CONNECTOR
TUBE FITTINGS
HEMOCHRON
®
Jr. Signature Service Manual 18
FIGURE 3
MOTOR
CONNECTOR
(SAMPLE)
J5
MOTOR
CONNECTOR
(WASTE)
J4
LED HARNESS
ASSY CONNECTOR
J1
