Technical Specification
Parameter IT-M7722L
Max. output power
600VA
Max. output voltage
300Vac
Output phase Single-phase
Current range(rms)
6A
Current range(peak)
18A
Output frequency range
45～100Hz
Phase angle degree range
0～359.9°
THD*1*3 ≤0.3% at 45～100Hz
Crest factor 3
Line Regulation *3
≤0.06%
Load Regulation *3
≤0.15%
Output voltage
(VAC)
Resolution 0.1V
Accuracy ±(0.2%+0.2% F.S.)
Frequency
Resolution 0.1Hz
Accuracy
±0.1%
Phase angle degree
range
Resolution 0.1°
Accuracy
0.5°
DC offset value 20mVdc
Efficiency 80% (Typical)
DC Output
Max. output power
600W
Max. output voltage
±400Vdc
Maximum output current (rms)
±6A
DC voltage Accuracy ±(0.2%+0.2% F.S.)
Dynamic response time (Full load of
10~90%)
≤0.5ms
Meter
AC Voltage
Range
0～300V
Resolution 0.1V
Accuracy ±(0.25%+0.25% F.S.)
AC current (rms)
Range
0.1～6A
Resolution 10mA
Accuracy ±(0.25%+0.25% F.S.)
