Operation and Application
a. Press the composite keys [Shift] + [I-set](Function) to enter function
menu interface.
1:List Mode = Off
2:List Trigger = On
b. Rotate the knob to select List Mode and press [Enter] key to confirm.
c. Rotate the knob to select the name of the List file to be run and press
[Enter] key to confirm.
• Off: Default value, indicating that the List Mode function is disabled.
• 1: indicate that the List Mode function is enabled, and List 1 file is
called.
• 2: indicate that the List Mode function is enabled, and List 2 file is
called.
• 3: indicate that the List Mode function is enabled, and List 3 file is
called.
• 4: indicate that the List Mode function is enabled, and List 4 file is
called.
• 5: indicate that the List Mode function is enabled, and List 5 file is
called.
3. Set the trigger mode to run the List.
a. Select List Trigger in the Function menu interface and press [Enter] key
to confirm.
b. Rotate the knob to switch On and Off options. After selecting On or Off,
press [Enter] key to confirm.
• Off: After the Trigger key is pressed, the instrument will automatically
run the real-time List file.
• On: After the Trigger key is pressed, the instrument will run the real-
time List file in single step.
c. Press [Esc] to exit the function menu setting.
4. Press the [On/Off] key to turn on the instrument output.
50.0V 3.00A 50.0Hz
List 5 Step 0/ 7 Stop
5. Press the composite keys [Shift] + [On/Off](Trigger) on the front panel to
run the selected List file.
50.0V 3.00A 50.0Hz
List 5 Step 1/ 7 Run
• When List Trigger = On, press the Trigger key once, and the instrument
will run one step of List output.
• When List Trigger = Off, the instrument will output based on defined List.
IT-M7721L/IT-M7722L do not support list function.
Copyright © Itech Electronic Co., Ltd.
63
