Iveco Motors Cursor 13 Series User Manual

11
ENGLISH
Startup procedure from IVECO MOTORS
secondary panel or fly-bridge (provided upon request)
1 Enable the secondary panel operation by turning the key
switch on the main panel to 8B position (see instructions
and procedure described in the previous paragraph).
2. Wait for the acoustic alarm to stop and that the warning lights (5)
on the signaling module are switched off (except for "alternator
recharge" and "oil low pressure"). At the same time check that
testing of indicators is successful (see relevant section as regards
test reading and module indication instructions).
3. Press the green push button (5) and release it upon startup.
4. Check that the revolution indicator reading is acceptable.
1. Tachometer and hour counter - 2. Horn - 3. Alarms and signaling
module - 4. Horn silencing push button - 5. Engine Start push button -
6. Engine stop push button.
WARNING
For the onboard control panels to fully perform their relevant
operations during navigation, it is essential that the engine startup is
done only after the completion of warning lights and horn testing.
5
1 3
2
6
4
04_355_N
