DAILY 4x4 ‒ GUIDELINES FOR BODYBUILDERS
ELECTRONIC SUB-SYSTEMS
5.2 BODYBUILDER CONNECTORS
9
– Printed 692.68.999 – 3 Ed. - Base 08-2020
Pin Description
Cable
code
signal
Connected
to
Remarks
23
Ground for Multiple State
Switch
0000
Output
max 15 A
BCM H/36
ISC input (Idle Speed Control) mode 1/2/3
(9)
the ISC mode must be reactivated after every engine
start-up.
24 Ground 0000
Output
max 15 A
Ground connection
25 K15 Remote 8879
Input
Max 200 mA
SCM B/67
By providing a positive, the first turn of the key is simu-
lated (key set to ON). Only the main loads are powered
but it is not possible to start the vehicle from outside
since the vehicle key recognition is missing.
(10)
+12 V = activation of K15 Remote
26 Engine shut down 9903
Input
Max 10 mA
BCM F/22
The engine only switches off with vehicle speed < 4 km /
h
+ 12 V = engine stop
The command must be active until the engine is off
27 Service braking 1176
Output
Max 500 mA
BCM D/57 +12 V = brake pedal pressed
28 Stationary vehicle 0000
Output
Max 200 mA
(use a decoupling diode)
BCM H/32 Ground = vehicle stopped
29
Battery disconnecting
switch ON
0000
Input / output
Max 200 mA
+12 V = TGC closing
30 Battery positive K30 7772 max 15 A BCM E/19
Direct positive from the battery and protected by fuse
on Body Computer - F33
1) Vehicle equipped with Hi-Matic gearbox with trailer:
no current draw is possible
2) Vehicle equipped with Hi-Matic gearbox without
trailer: maximum current draw 7.5 A
3) Vehicle equipped with manual gearbox with trailer:
maximum current draw 7.5 A
4) Vehicle equipped with manual gearbox without trailer:
maximum current draw 15 A
31 N.D.
32 N.D.
(1)
The vehicle does not supply any safety check. The vehicle does not prevent engine start-up with gear engaged, nor
monitors the release of the clutch pedal. The bodybuilder must adopt preventative measures to avoid any uninten-
tional movements of the vehicle.
The engine start-up control must be permanently active until the engine starts running.
The engine only functions with the key turned in the ignition block (K15 ON).
Activating the remote signal K15 from pin 25 of connector 72105A and then inserting the key in the ignition block (K15 ON) prevents
engine start-up and an Immobilizer Error is signalled. In this case it is necessary to remove both the remote signals K15 and K15 ON.
When the procedure has been performed successfully it remains valid for the entire K15 ON cycle and this allows the bodybuilder to re-
peatedly stop and restart the engine until K15 stays active.
The starter motor is only activated when the engine is NOT running.
(2)
If the "parking brake engaged" signal indicates "ground", it means the parking brake has not been fully released.
Therefore a residual braking torque on the rear axle cannot be excluded. IVECO does not recommend use of the signal
as an indication of a stationary vehicle.
