CHASSIS MODIFICATIONS
2-1
DAILY 4x4
Print 603.93.761 Base - May 2007
Index
Index
SECTION 2
Chassis modifications
Page
2.1 General instruc t ions for ch assis modifications 2-5
2.1.1 Specific Prec a utions 2-5
2.2 Protection against Rust and Paintin g 2-7
2.2.1 Original components 2-7
2.2.2 Added or modified painted parts 2-10
2.2.3 Precautions 2-11
2.2.4 Exceeding the Limits 2-12
2.3 Drilling t he Chassis 2-13
2.3.1 Screws and nuts 2-13
2.3.2 Characteristics of the material to be used when modifying the chassis 2-13
2.3.3 Stresses on the c hassis 2-14
2.3.4 Welding the Chassis 2-15
2.3.5 Closing of existing holes 2-16
2.4 Modifying the Wheelbase 2-17
2.4.1 General Specifications 2-17
2.4.2 Authorisation 2-17
2.4.3 Consequences for steering 2-17
2.4.4 Effect on Braking 2-17
2.5 Modifying the Rear Overhang 2-18
2.5.1 Authorisation 2-18
2.6 Installing a Towing Device 2-18
2.6.1 General Specifications 2-18
2.6.2 Traditional towing hooks 2-19
2.6.3 Hook types 2-22
2.6.4 Lowered Rear Cross Member 2-22
2.7 Installing a Supplementary Axle 2-24
2.8 Modifying the Drive Line 2-24
2.8.1 Permitted lengths 2-24
