iWorX TM-100 - Page 4

Table 1: Resistances of the Thermistor Used in the TM-100 Temperature
Sensor at Different Temperatures
Temp
(°C)
Resistance
(Ω)
Temp
(°C)
Resistance
(Ω)
Temp
(°C)
Resistance
(Ω)
0 32650.5 17 14321.6 34 6808.36
1 31032.1 18 13679.8 35 6531.31
2 29499.9 19 13070.4 36 6265.75
3 28052.4 20 12491.6 37 6016.47
4 26684.6 21 11941.6 38 5776.05
5 25391.2 22 11418.9 39 5546.53
6 24168.2 23 10922.0 40 5327.34
7 23011.2 24 10449.5 41 5117.97
8 21916.3 25 10000.0 42 4917.94
9 20879.8 26 9572.32 43 4726.77
10 19898.3 27 9165.29 44 4543.91
11 18968.6 28 8777.79 45 4369.33
12 18087.6 29 8408.68 46 4200.84
13 17252.6 30 8057.31 47 4040.81
14 16460.9 31 7722.43 48 3889.51
15 15710.0 32 7403.29 49 3743.17
16 14997.7 33 7098.42 50 3603.10
iWorx Systems, Inc. 62 Littleworth Road, Dover, New Hampshire 03820
(T) 800-234-1757 / 603-742-2492 (F) 603-742-2455
TM-100 Temperature Sensor
iWorx Systems, Inc.
www.iworx.com
