Assembly and Operating Manual Explorer prop
6
Fig
Fig. 13
- Connect the battery and ESC
Fig. 14
- Congratulations, you have completed the
assembly process. We hope you enjoy flying your
new model!
Fig. 15 Photo shows the balancing weight.
- Place the canopy on the fuselage.
- Place the battery in the model of balancing; do not
connect it.
- Make the Centre of Gravity on both sides.
- Support the model at the marked C.G. and allow it
to hang freely. The model is correctly balanced
when it hangs level, ideally with the nose inclined
slightly down.
- Adjust the position of the flight battery if necessary.
- Mark the battery location in the fuselage, so that
you can be confident of replacing it in the same
position after removing it.
13
14
15
