Jabra GN9350e
4
Jabra PRO™ 9400
series
Jabra GO™ 6470
OR OROR
Jabra GN9350e/
Jabra GN9330e EHS
Jabra GN9120/
Jabra GN9125 EHS
Electronic Hook Switch (EHS) Solutions for Aastra
SUPPORTED AASTRA IP PHONES
Regional sales contacts:
Americas: Bill Orlansky, borlansky@gn.com
EMEA: Norbert Lohwieser, nlohwieser@gn.com
APAC: Mike Powrie, mpowrie@gn.com
For more information visit www.jabra.com/aastra
SEE THE LAST PAGE FOR ORDER INFO
Aastra 6771
Aastra 6773/ip
Aastra 6775/ip
Aastra 5370
Aastra 5370ip
Aastra 7434ip
Aastra 5380
Aastra 5380ip
Aastra 6751i
Aastra 6753i
Aastra 6755i
Aastra 6757i
Aastra 6757i CT
- only available in NA
Jabra LINK™ 14201-10
EHS Adapter
Aastra DHSA cable kit
- available from your
Aastra reseller
Jabra LINK™ 14201-10
EHS Adapter
SET UP INFORMATION
To connect your Aastra phone and Jabra headset with the DHSG cable, just follow these simple
steps:
Setting up the Aastra IP phone
Plug the single end of the Y cable in the headset socket on the phone’s acoustic adaptor1.
Connect the large plug in the other end to the AUX port on the headset base2.
Plug the smaller RJ9 in the normal phone socket on the headset base3.
Setting up Jabra PRO 9400 and Jabra GO
6400 - follow the guide on page 11.
Setting up Jabra GN9350e series
Open up the cover on the base unit. 1.
On the LCD display, navigate to the 2.
handset picture.
Navigate to the DHSG mode and select 3.
it by pressing the OK button.
Set Compatibility selector in position “A”4.
.
Setting up Jabra GN9330e EHS
Place headset on base station.1.
Push simultaneously 5 sec on the 2 2.
buttons (base station and headset
– see illustrations next column)
LED on headset starts to blink rapidly 3.
Choose EHS mode with volume control 4.
on headset. LEDs on base indicates
selected mode: LED 2: DHSG mode
After setting wait a few seconds. 5.
When LED on headset stops blinking,
start using headset.
Setting up Jabra GN9120/GN9125 EHS
Set compatibility selector (1.
Telephone
Termination Switch Wheel
)
in position “A”
Set the base unit to the DHSG mode 2.
by keeping the headset in the base
and hold the volume +/- buttons on
the headset for 6 seconds until the red
light on the base flashes rapidly.
Scroll through the four different 3.
settings using +/- and set to the lips
icon. Leave for 15 seconds until the
unit has displayed the confirmation
flash sequence and it is ready to go!
