Rightandleftsideboards
1.Releasethelockknucklesoftherearboard.
2.Movethefastenedhandleleftwardbeforeputtingdowntheverticallockout鄄
wardstoreleaseit.
3.Liftupthehookhandleonthefrontendofthesideboardtoreleasethefront
hook.
4.Atthistime,thefrontendofthesideboardisstillfastenedbytheboard
clamp.Pullouttheboardclampwithforcetoletfreethesideboard.
5.Toclosethesideboard,securelylockupthefrontendofsideboardwiththe
hookhandle,andputitintotheverticallockoftherearboardbeforefasteningit
withthehandle.
32
OWNER爷SMANUAL
JACHighendLightTrucks
Outerlights
Front:
1.Frontturnsignallamps;
2.Foglight;
3.Frontside-markerlight;
4.Headlight.
Rear:
Therearlightsetisinstalledinthepositionshownontheleftfigure,withthe
following:
1.Back-uplight;
2.Turnsignallights;
3.Brakelights;
4.Rearside-markerlight;
5.After-reversionreflector.
Turmsignallight
Brakelight
Rearlight
Rearfo
glight
Revers
elight
Non-returnreflector
33
