Wheelcylinder
Ventingscrew
Locknut
Adjustingnut
Clutchshifter
Mastercylinder
Pedaladjustingbolt
Adjustingnut,tightening1.5~2.5kg.m
3.Filterelementtreatment
Cleaningofthefilterelementisdoneinoneofthefollowingmethodsdepen鄄
dentonitscontamination.
Thefilterelementisdustcontaminatedbutstilldry:
Turningtheelementwithhand,andblowoffthedustfromitsinsidewithcom鄄
pressedair,whosepressureshouldbebelow7kg/cm2.
Clutchpedaladjustment
1.Loosentheblockingboltortheclutchswitch,andadjusttheclutchpedal
heighttothespecifiedvalue. 2.Loosenthelocknutandadjustingnutofthe
follow-upcylinder.Screwdowntheadjustingnutuntilitcontactstheclutchshift
fork,andthenscrewitbackforoneandahalfround.
3.Tightenthelocknut.
4.Adjustthepushrodlengthofthemastercylinder,tobringthebacklashofthe
clutchpedaluptothespecifiedvalue (thisneedn'tbedoneintrucksprovided
withservomechanism).
5.Adjusttheclutchswitchgap(L),tokeepitwithin0.5-1.0mm.
116
OWNER爷SMANUAL
JACHighendLightTrucks
Clutchpedalbacklashandstandardheight
(1)Backlash:15-25mm
(2)Height:205-213mm
Fuelfilter
1.Loosenthefiltercounterclockwisewithafilterspanner.
2.Cleanthematingsurfaceofthefilterbonnetwithapieceofcloth,inorderto
havethefilterinstalledfirmlyonthematingsurface.
117
