schematicofdifferentfuseinstallation

15A 10A 15A 15A 15A 15A 20A 15A 15A 30A 15A 20A 30A 20A 15A 20A 15A 15A 10A 30A

Normal broken

Ifthefuseisfoundbroken,checkandtrytofindoutthereasonforthat.Take

necessarymaintenancemeasuresbeforefusereplacement.

Beforechangingthefuse,turnthestartswitchto"LOCK"position,andmust

usefusesofthesamecurrentrating.

134

OWNER爷SMANUAL

JACHighendLightTrucks

Frontlightset

Whenreplacingbulbs,takedownthecoverfirst,thenthedecorationbandsfor

theheadlightsscrewoffthe4screws,andthebulbscanbetakenout.

Rearlightset

Whenreplacingthebulbs,youhavetotakedownthetaillightbeforetakingout

thebulbfrombehindthetaillight.

Non-returnreflector

Turnsignallight

Brakelight

Rearlight

Rearfoglight

Reverselight

135
