thelockingfunctionoflockarmon
therearbracket,thenlowerthecab
downslowly.Afterthesafetylockbe
locked,fastenthelockingmech-
anism.
Inspectionandmaintenance
1.Checkperiodicallytherubberpad
assemblies which are used to
strengthenthefront尧rearsupport,if
found damaged, it should be
replacedinstantly.
2. Check periodically the locking
situationofthelockingmechanism,if
foundnotwork,itshouldberepaired
orreplacedimmediately.
3.Ifitisdifficulttotiltupthecaband
putitdown,thetorsionrodcannot
work.Replacethetorsionrod.
4.Whenrepairingthechassis,before
removingthecab,disengagethe
forceofthetorsionrodandoperate
withthefollowingsteps.
荫 Disengagethelockingstate,and
tiltupthecabtothehighestposition.
荫 Removetheshaftpinconnected
the rear support rod and the
baseboardsupportofthecab.
荫 Pushthecabforwardtosome
angleuntiltheboltonthetorsionrod
armcanbeloosened.
荫 Aftertheboltremoved,thetorsion
rodcannotwork.Nowthecabcan
beremoved(Thetorsionrodcannot
bepulledout).
5.Beforerevertingthecabtothe
originalposition,returntheforceof
14
OWNER爷SMANUALfor
HFC1061,HFC1063,HFC1083
seriestrucks
Note: Thementionedabovework
mustbedonebythreepersons
atleastbecausetwoorthree
personscannotpushthecab
forwardaftertheforceofthe
torsionroddisengaged.
thetorsionrodandoperatewiththe
followingsteps:
荫 Putthetoothpartofthespline
whichiscutatthebottomononeend
ofthetorsionrodinalignmentwith"1"
positiononthesupportaxletubeand
thesplinetube,andinsertthetorsion
rodintothesupportaxletube(forthe
rodwhichispulledout).
荫 After mounting the cab with
supportaxletubeandtheleft尧 right
brackettogethertotheframe,putthe
"1"ofhubsplinesonthetorsionrod
inalignmentwiththesplinetooth
whichiscutatthebottomonthe
otherendofthetorsionrod,cover
thehubsplinesonthetorsionrod
andinsertthesplineaxletubeinto
therightbracketinthecab.
荫 Tiltthecabforwarduntilthebolt
holeonthetorsionrodarmaimedat
thescrewedholeontherightbracket
inthecab,screwtheboltandtighteni.
荫 Putthecabdownslowly,and
checkwhetherthecabisonthe
stateofsuspendinginthehorizontal
directionafterdroppeddown.Ifit
worksnormally,lockthecab.
6.Iffindingthetorsionrodnotwork,
referringto(4)(5)whenreplacingit.
Startingandrunningofthe
vehicle
Startingofthevehicle
Startingoftheengine
Aftermakingpreparationsforstarting
engine,first,puttheshiftbaronthe
neutralposition,turnontheignition
switch,thencheckhorns尧instruments
on the instrument panel尧turning
lamps尧brakinglamps尧theangleand
positionoftherearviewmirror.
1.Routinestart
TurnthekeytotheSTARTposition(As
shownontherightfigure),theengine
canstart.Afterstarting,loosenthe
acceleratorpedalimmediatelyand
keeptheengineworkinginlowspeed.
Pressing the accelerator pedal
15
