JAC HFC4DA1-2C - Page 240

IP Instrument
Instrument
Instrument
Instrument and
and
and
and Warning
Warning
Warning
Warning System
System
System
System
- 32 -
Diagnosis
Diagnosis
Diagnosis
Diagnosis and
and
and
and Test
Test
Test
Test
Definitions
Definitions
Definitions
Definitions of
of
of
of instrument
instrument
instrument
instrument pins
pins
pins
pins
Terminal NO. Terminal name Terminal NO. Terminal name
A1 Back lighting (-) B1 Right turn (+)
A2 Back lighting (+) B2 Upper beam (+)
A3 Frequency division output B3 NC
A4 Main relay B4 Instrument LIN communication
A5 Oil-water separator (+) B5 NC
A6 NC B6 NC
A7 NC B7 NC
A8 NC B8 NC
A9 NC B9 NC
A10 Engine fault (-) B10 NC
A11 Charging indicator lamp (-) B11 NC
A12 Engine oil pressure (-) B12 NC
A13 Brake fault (-) B13 NC
A14 Engine inspection (EPC)(-) B14 NC
A15 NC B15 NC
A16 Engine fault (-) B16 NC
A17 NC B17 Parking brake (-)
A18 Water temperature signal B18 Preheating (-)
A19 Fuel signal B19 Seat belt (-)
A20 Vehicle speed signal B20 Door open indicator lamp (-)
A21 Speed signal B21 NC
A22 Constant power supply B22 Rear fog lamp (+)
A23 GROUND B23 Front fog lamp (+)
A24 Ignition B24 NC
A25 GROUND B25 NC
A26 NC B26 NC
A27 ABS B27 NC
A28 NC B28 NC
A29 GROUND B29 NC
A30 NC B30 NC
A31 NC B31 NC
A32 Left turn (+) B32 NC
