ET
ET
ET
ET ETACS
ETACS
ETACS
ETACS Body
Body
Body
Body Computer
Computer
Computer
Computer
- 46 -
Diagnosis
Diagnosis
Diagnosis
Diagnosis and
and
and
and Testing
Testing
Testing
Testing
Introduction
Introduction
Introduction
Introduction to
to
to
to ETACS
ETACS
ETACS
ETACS functions
functions
functions
functions
With the middle door open, if you press
Unlock key on the remote control, the middle
door shall be locked in 0.5 sec after the door is
closed. (Please refer to the left figure.)
18. Password Learning Input
If you press the password learning switch, the
fault lamp shall lighten entering into password
learning mode. The learning time is 10 sec in
total.
Press every key of the remote controller once.
The fault lamp shall go out after the first key is
pressed. Four keys in total can be learned
within 10 sec after starting the password
learning key.
Conduct detection for remote control password
learning.
Enter into password learning mode with the
previous memory deleted automatically.
Remote control
locking
Middle door
switch signal
Middle door
lock status
signal
Door locking
output action
Open
Closed
Unlock
Lock
