13. Hazard warning lamp failed but with normal operation of turn signal lamps
Step Operation
Yes
No
1 Is the fuse intact? Go to Step 3. Go to Step 2.
2 Replace the damaged fuse . Is the hazard warning lamp normal? Go to Step 3.
3 Remove the hazard warning switch and check if it is normal. Go to Step 4.
4 Check if the voltage of hazard warning lamp switch is normal? Go to Step 6. Go to Step 5.
5 Check the instrument panel harness from fuse to hazard warning lamp switch.
6 Check the ground wire of hazard warning lamp switch. Is it normal? Go to Step 8. Go to Step 7.
7 Check the ground wire of instrument panel harness.
8 Check the lead from instrument panel harness to hazard warning lamp switch.
