JAC HFC4DA1-2C - Page 403

AT
AT
AT
AT Air
Air
Air
Air Conditioner
Conditioner
Conditioner
Conditioner
- 194 -
Removal/Installation
Removal/Installation
Removal/Installation
Removal/Installation
Removal
Removal
Removal
Removal of
of
of
of top
top
top
top evaporator
evaporator
evaporator
evaporator tank
tank
tank
tank
5. Disconnect the A/C drain pipe.
6. Remove mounting bolts from expansion valve.
7. Remove mounting bolts.
8. Remove the top evaporator tank assembly.
