JAC HFC4DA1-2C - Page 406

AT
AT
AT
AT Air
Air
Air
Air Conditioner
Conditioner
Conditioner
Conditioner
- 197 -
Removal/Installation
Removal/Installation
Removal/Installation
Removal/Installation
Removal
Removal
Removal
Removal of
of
of
of bottom
bottom
bottom
bottom condenser
condenser
condenser
condenser
1. Recover refrigerant.
2. Disconnect negative cable of battery.
3. Remove mounting bolts and disconnect pipeline.
4. Remove bottom condenser assembly.
