JAC HFC4DA1-2C - Page 416

AT
AT
AT
AT Air
Air
Air
Air Conditioner
Conditioner
Conditioner
Conditioner
- 207 -
Removal/Installation
Removal/Installation
Removal/Installation
Removal/Installation
Removal
Removal
Removal
Removal of
of
of
of front
front
front
front A/C
A/C
A/C
A/C control
control
control
control panel
panel
panel
panel
1. Disconnect negative cable of battery.
2. Remove outer cover plate of A/C control panel.
3. Remove mounting bolts from A/C control panel
and disconnect harness.
4. Remove the A/C control panel.
