ASSEMBLY INSTRUCTIONS — 636 JUMBO JACK
5
1. Fully insert five casters into base as shown and secure each with set screw provided.
2. Insert V-head into center tube of base.
3. Using adjusting handle, raise or lower V-head.
STEEL ROLLER
ADJUSTING
HANDLE
BASE
V-HEAD
SET SCREWS (5)
ONE PER CASTER
CASTERS (5)
